BEP Marine Pro Installer 400A EZ-Mount Double Pole Battery Switch (770-DP-EZ)

The BEP Marine Pro Installer 400A EZ-Mount Double Pole Battery Switch provides on/off functionality for isolating both positive and negative battery terminals. Designed for surface mounting, this switch is ideal for metal-hulled vessels to prevent stray currents and galvanic corrosion, while also ensuring safety during maintenance on marine or mining equipment. The EZ-Mount design allows for front-wire access and features a shared interconnection height for direct clustering with the Pro Installer Busbar range.

Key Features:

• 400A continuous, 600A intermittent (5 minutes), and 1500A cranking (10 seconds) ratings.
• Voltage rating: 48V DC (suitable for 12-48V systems).
• Tinned copper 10 mm (3/8 in.) studs with stainless steel hardware.
• Waterproof rating: IP67.
• Ignition protected (tested to UL 1107) and CE certified.
• Footprint: 3.85 in. x 3.85 in.; overall dimensions: 3.85 in. x 3.85 in. x 3.62 in.
• Includes a removable knob for service isolation and three removable side plates for cable protection.
• Construction: Fiber-reinforced plastic.

Regulatory note: This product contains chemicals including di(2-ethylhexyl)phthalate (DEHP), which is known to the State of California to cause cancer, birth defects, or other reproductive harm.
