Blue Sea Systems WeatherDeck 2-Position Fuse Panel, Gray, IP67

Blue Sea Systems WeatherDeck 2-Position Fuse Panel, Gray, IP67

SKUCT-100372

$55.03
$55.03
Sale Sold out
Shipping calculated at checkout.
Shipping rewards at $100 U.S. orders of $100 or more get free standard shipping, plus $10 off Expedited and Overnight.

Low stock

Use the Tug & Tow SKUInclude this SKU when you contact us about fit, availability, or reorders.
Delivery shown at checkoutShipping options, final costs, and delivery estimates appear before payment.
Check fit before orderingReview dimensions, part numbers, model details, and compatibility notes.
Confirm the details before checkoutFit can depend on your boat, RV, trailer, vehicle, or equipment. Contact us before ordering if compatibility is critical.Ask a product question

Product details

Review the details before ordering.

Ensure relentlessly reliable circuit protection in demanding marine and outdoor environments with the Blue Sea Systems WeatherDeck Water Resistant Fuse Panel. This 2-position, gray panel boasts an IP67 rating, offering superior protection against water immersion, making it ideal for exposed locations like flybridges and open cockpits. Its intuitive bicolored LEDs provide instant circuit status, simplifying diagnostics on the go. Upgrade your vessel's electrical system with the proven durability and performance of Blue Sea Systems.

In the Box:
  • Blue Sea Systems 4302 WeatherDeck Fuse Panel
  • (2) Blue Sea Systems 4150 WeatherDeck® Toggle Switches SPST - ON-OFF
  • (1) Blue Sea Systems 4215 Waterproof DC Label Kit (30 Black Square Labels)
  • (2) Blue Sea Systems 5242 ATO/ATC Fuses - 15 Amp
Key Features & Benefits:
  • Superior Water Resistance: IP67 rated for complete immersion protection up to 1 meter for 30 minutes, ensuring reliable operation in the harshest conditions.
  • Durable Construction: Crafted from reinforced polycarbonate, designed for lasting performance in marine applications.
  • Versatile Circuit Protection: Two integrated ATO/ATC fuse-based circuits, each rated at 15A, protect essential 12V DC systems.
  • Intuitive Circuit Status: Bicolored LEDs clearly indicate circuit status – Green for ON, Red for OFF, and no illumination for a blown fuse, allowing for quick troubleshooting.
  • Enhanced Visibility: Independent label backlighting circuit enables remote switching and dimming, maintaining readability in low-light conditions.
  • Flexible Installation: Engineered to be mounted in four different orientations, adapting easily to various space requirements.
  • Robust Power Handling: Features a 15A maximum amperage per circuit and a 30A panel cumulative rating to secure critical components.
Specifications:
  • Positions: 2
  • Nominal Voltage: 12V DC
  • Circuit Protection: ATO/ATC Fuse
  • Maximum Amperage (per circuit): 15A @ 12V DC
  • Panel Cumulative Rating: 30A
  • Backlighting Amperage: 10mA/illuminated Circuit
  • Backlighting Voltage: 12V DC
  • Height: 2.6 inches (66.04 mm)
  • Width: 3.88 inches (98.55 mm)
  • Depth: 2.5 inches (63.5 mm)
