Blue Sea Systems 187-Series 90A Thermal Circuit Breaker, Panel Mount
Blue Sea Systems 187-Series 90A Thermal Circuit Breaker, Panel Mount
Last one
The Blue Sea Systems 187-Series Thermal Circuit Breaker combines switching and circuit protection in a single, waterproof device. Rated for 90 Amps, this Type III manual reset breaker features a trip-free design that prevents the switch from being held on during a fault condition. It is ignition protected, making it suitable for installation aboard gasoline-powered boats.
- Ignition Protected: Meets SAE J1171 requirements for safety in gasoline-powered environments.
- Design: Thermally responsive bi-metal blade with clear, single-lever operation.
- Voltage Rating: 48V DC maximum.
- Interrupt Rating: 5,000A at 12V DC, 3,000A at 24V DC, and 1,500A at 42V DC.
- Installation: Recessed mounting holes and self-trimming case for a clean, flush appearance.
- Terminal Specs: Robust 5/16" terminal studs accommodate heavy-gauge wire lugs.
- Temperature Range: -25°C to +82°C.
- Manufacturer Part Number: 7043.
- Regulatory Note: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (DEHP), which is known to the State of California to cause cancer, birth defects, or other reproductive harm.
Product facts
- CT SKU
- CT-100425
- Model / MPN
- 7043
- UPC / GTIN
- 632085070434
- Package dimensions
- 3" X 5" X 8"
- Package weight
- 0.3 lb
- Specifications
- Amperage = 90a
Fit-sensitive item: confirm measurements, model numbers, and manufacturer details before ordering. Tug & Tow does not guarantee universal compatibility from a product page alone.
