Blue Sea Systems 187-Series 200A Panel Mount Circuit Breaker, Waterproof

Ensure robust electrical protection and reliable switching for your marine systems with the Blue Sea Systems 187-Series Panel Mount Circuit Breaker. Engineered for demanding environments, this 200 Amp breaker combines essential circuit protection with a manual reset switch in a single, robust device. Its waterproof and ignition-protected design makes it safe and ideal for use aboard gasoline-powered boats. Upgrade your vessel's safety and performance today.

• High Current Rating: A 200 Amp capacity provides substantial power handling for critical marine loads.
• Integrated Functionality: Combines both switching and circuit protection, simplifying your electrical panel and operation.
• "Trip Free" Design: Cannot be held "ON" during fault conditions, ensuring maximum safety and preventing system damage.
• Marine-Grade Durability: Waterproof to IP66 standards and ignition protected (meets SAE J1171), making it safe for harsh marine conditions and gasoline engine compartments.
• Robust Terminal Connections: Features robust 5/16"-18 (M8) terminals that accept heavy-gauge wire lugs and allow for high-torque connections, ensuring secure electrical contact.

• Interrupt Rating: 5,000A @ 12V DC, 3,000A @ 24V DC, 1,500A @ 42V DC for reliable fault interruption.
• Maximum Voltage: Rated for 48 Volts DC systems.
• Operating Temperature Range: Functions reliably from -40°C to 85°C.
• Circuit Breaker Type: Thermally responsive bi-metal blade for consistent performance.
• Circuit Breaker Class: Type III - switchable/manual reset, trip-free.
• Mounting: Panel mount with recessed mounting holes for a clean appearance.
• Weight: 0.50 lbs (0.23 kg).
• Case Material: Durable Thermoset Polyester.
