Blue Sea Systems Push Button Reset Only Quick Connect Circuit Breaker, 5 Amps

Ensure vital circuit protection and maintain electrical integrity in your marine or automotive application with the Blue Sea Systems 7052 Push Button Reset Only Quick Connect Circuit Breaker. Designed for reliable, economical circuit protection, this 5 Amp thermal breaker is ideal for small boat applications and can be incorporated into Blue Sea Systems' Waterproof Circuit Breaker panels and main Battery Main Distribution Panels, offering 24-hour protection. Its ignition-protected design makes it safe for installation aboard gasoline-powered boats, meeting UL1500 and ISO8846 standards. Upgrade your vessel's electrical system for enhanced safety and performance.

Key Benefits & Specifications:

• Economical Protection: Provides reliable circuit protection for loads up to 5 Amperes.
• Push-to-Reset Operation: Allows for quick and easy circuit restoration after a fault.
• Male Quick Connect Terminals: Ensures simple, secure, and fast wiring installation.
• Ignition Protected: Safe for installation aboard gasoline-powered boats, meeting UL1500 and ISO8846 ignition protection requirements.
• Trip-Free Design: Cannot be held ON during a fault, guaranteeing the circuit remains open until the fault is cleared to prevent damage.
• Compact Design: Enables high-density circuit protection configurations, perfect for optimizing panel space.
• Maximum Voltage: Supports systems up to 32V DC.
• High Interrupt Capacity: Rated for 3000A at 14.7V and 2500A at 28V for robust fault handling.

Compatibility & Pairings:

• Easily integrates into Blue Sea Systems WeatherDeck Waterproof Circuit Breaker Panels, Dual Battery Bank Main Distribution Panels, and 360 Distribution Panels.
• For wet environments, consider pairing with an optional Blue Sea Systems Push Button Waterproof Boot (sold separately) to protect the circuit breaker.
