Blue Sea Systems 8380 DC Main + 22 Position Circuit Breaker Panel, 12/24V 100A

Master your vessel's power distribution with the Blue Sea Systems 8380 DC Main + 22 Position Circuit Breaker Panel. Engineered for robust performance and efficient management of your DC electrical systems, this panel combines a high-amperage main breaker with extensive branch circuit protection. Its pre-wired design and comprehensive features simplify installation and ensure reliable, long-lasting operation in marine and demanding environments. Upgrade your power management for unparalleled control and safety.

In the Box:

• Blue Sea Systems 8380 DC Main + 22 Position Circuit Breaker Panel
• (16) A-Series White Toggle Single Pole Circuit Breakers (15A)
• (1) C-Series Main Circuit Breaker (100A)
• (1) 8028 DC Micro Voltmeter (8-16V DC)
• (1) 8250 DC Analog Micro Ammeter (0-100A)
• (1) Basic DC Panel Label Set (30 Labels)
• Detailed Installation Instructions and Cutout Template

Key Benefits & Specifications:

• Comprehensive Circuit Protection: Features a 100A C-Series main circuit breaker and 22 positions for A-Series branch circuit breakers, providing extensive protection for your electrical system.
• Flexible Voltage Compatibility: Operates at 12V DC nominal voltage and is owner-upgradable to 24V DC with optional meters (8240 or 8243), accommodating various system requirements.
• Simplified Installation: All positive, negative, and grounding buses are pre-installed and fully pre-wired to streamline setup and reduce wiring time.
• Durable Construction: Crafted from heavy 1/8" aluminum 5052 alloy with a two-part polyurethane slate gray finish for exceptional strength and corrosion resistance.
• Enhanced Visibility: All circuit label positions are backlit, and 'ON' indicating LEDs are installed in all circuit positions for clear identification in any lighting condition.
• Corrosion Resistance: Features MIL-C-5541C or equivalent immersion undercoating for lifetime protection against harsh marine environments.
• Battery Bank Monitoring: Includes a toggle switch on panels with meters, allowing for monitoring of up to 3 battery banks for comprehensive power management.
• Flush Mounting: Countersunk mounting holes ensure a clean, flush, and secure installation.

Compatibility & Pairings:

• Compatible with Blue Sea Systems 8240 or 8243 (18-32V DC) meters for 24V system upgrades.
