Digital Yacht GPS160 QuadNav GNSS Sensor with SeaTalk1 Converter, 18Hz

Elevate your marine navigation with unparalleled accuracy and reliability using the Digital Yacht GPS160 QuadNav GNSS Sensor. This advanced positioning sensor leverages signals from GPS, Glonass, Galileo, and Beidou satellite systems simultaneously, ensuring superior global coverage and redundancy for critical positioning data. Designed as a direct replacement for older Raystar sensors, this bundle includes a dedicated SeaTalk1 to NMEA0183 converter for seamless integration into existing networks. Experience smooth, real-time data for your plotter and enhance onboard safety with integrated MOB functionality. Upgrade your vessel's intelligence with the GPS160 QuadNav today.

In the Box:

• Digital Yacht GPS160 GNSS Sensor with 10m cable
• Digital Yacht SeaTalk1 to NMEA0183 Converter

Key Benefits & Features:

• Quad-Constellation Support: Utilizes GPS, Glonass, Galileo, and Beidou satellite systems for exceptional positioning accuracy and redundancy, providing the best possible fix even in challenging environments.
• Superior Accuracy: Achieves typically sub 1-meter (better than 3 ft) accuracy, ensuring precise navigation and plotter displays.
• High-Speed Data Output: User-selectable update rates up to 18Hz deliver smooth, real-time position data for your chart plotter.
• Ultra-Low Power Consumption: Draws less than 20mA at 12V DC, ideal for extended use without significant battery drain.
• Integrated MOB Functionality: Supports an external Man Overboard (MOB) switch, generating a synthetic AIS SART MOB message on the NMEA output to quickly identify and navigate to a casualty.
• Advanced Anti-Spoofing: Features a sophisticated algorithm to ensure robust positioning performance and rejection of interference.
• Versatile Configuration: Field-programmable for single GNSS operation (e.g., Galileo only) and user-selectable NMEA baud rates (4800, 38400, 115200) and sentence structures via internal DIP switches.
• Flexible Installation: Designed for puck installation or compatibility with industry-standard 1” x 14TPI threaded mounts.
• SeaTalk1 Integration: Directly replaces older Raystar sensors, with the included converter providing bi-directional conversion between SeaTalk1 and NMEA0183 networks while powering from the SeaTalk1 network.
• Professional System Compatibility: Supports Electronic Chart Display and Information Systems (ECDIS) with comprehensive datum sentence structures.

Compatibility & Pairings: The included SeaTalk1 to NMEA0183 converter ensures seamless integration with existing SeaTalk1 networks and NMEA 0183 compatible chart plotters and navigation systems. For NMEA 2000 systems, an iKonvert interface (sold separately) is required.
