Egis Mobile Electric Automatic Charging Relay Plus, 160A, 24V

The Egis Mobile Electric Automatic Charging Relay Plus is a 160A, 24V relay designed to prevent dead-start batteries by sharing charging between two batteries while isolating them when no charge sources are present. This unit is built for durability with sealed construction, stainless steel self-locking hardware, and high-temperature materials, allowing for flexible mounting.

Key Features:

• Eliminates dead-start batteries through intelligent charge sharing and isolation.
• Ultra-low power draw (1.3 mA) prevents battery depletion during extended downtime.
• Integrated status LED diagnostics for relay state, voltage, temperature, and start isolation/assist.
• Start assist input allows for manual battery connection via a remote switch for maximum cranking amps.
• Supports independent charge system isolation for multi-engine setups.
• Includes Deutsch/Amphenol DTM connector harness with integrated sealed Molex MX-150 connector.
• Thermal overload shutdown protection included.

Technical Specifications:

• Continuous Current: 160 Amps
• Interrupt Current: 240 Amps
• Voltage Range: 16 to 36 VDC
• AC Closing Voltage: 25.8 to 27.2 VDC
• AC Opening Voltage: 24.2 to 25.6 VDC
• Model Number: 7610-24
