Jabsco Par-Max HD4 Heavy Duty Water Pressure Pump, 24V, 4 GPM, 60 PSI

The Jabsco Par-Max HD4 is a heavy-duty water pressure pump designed for marine applications, featuring a durable motor with a powder-coated shell and cast aluminum endbells for improved performance and longevity. This 24V pump provides 4 GPM flow and 60 PSI pressure, utilizing co-molded diaphragm technology for reliable, long-term operation.

Key Features:

• Integrated, sealed pressure switch for on-demand operation
• Integrated bypass module to reduce cycling and provide smoother flow
• Self-priming capability with the ability to run dry without damage
• Quick connect ports for simplified installation and maintenance
• Vibration-dampening mounting feet for quiet, efficient performance
• IPX6 ingress protection rating
• Compatible with fluid temperatures from 32°F to 140°F
• Maximum inlet pressure of 30 PSI

Specifications:

• Model Number: Q402J-118S-3A
• Motor Type: Brushed, permanent magnet TENV
• Pump Head Material: Glass fiber reinforced polypropylene
• Diaphragm Material: Co-molded TPV
• Check Valve Material: EPDM
• Dry Self-Priming Capability: Up to 7 ft.
• Certifications: CE, ISO8846, RCM
• Regulatory note: This product contains chemicals including antimony oxide, which is known to the State of California to cause cancer.
