Brand: Jabsco
Jabsco Par-Max HD5 Heavy-Duty Water Pressure Pump, 12V, 5 GPM, 60 PSI, P501J-118S-3A
Jabsco Par-Max HD5 Heavy-Duty Water Pressure Pump, 12V, 5 GPM, 60 PSI, P501J-118S-3A
8 available
About this product
The Jabsco Par-Max HD5 is a 12V heavy-duty water pressure pump delivering up to 5 GPM at 60 PSI. Its self-priming design, sealed pressure switch, integrated bypass module, and vibration-dampening mounting feet support reliable on-demand water-system operation in marine applications.
- Flow rate: 5 GPM
- Maximum pressure: 60 PSI
- Motor: Brushed, permanent-magnet TENV
- Pumphead upper housing: Glass-fiber-reinforced polypropylene
- Diaphragm: Co-molded TPV
- Check valves: EPDM
- Maximum inlet pressure: 30 PSI
- Fluid temperature range: 32 deg F to 140 deg F
- Dry self-priming capability: 7 ft. minimum
- Features: Efficient and quiet operation, dry-run capability, quick-connect ports, vibration-dampening mounting feet, and an integrated bypass module
- Ingress protection: IPX6
- Certifications: CE, ISO8846, and RCM
- Manufacturer part number: P501J-118S-3A
- Regulatory note: This product can expose you to antimony oxide (antimony trioxide), a chemical known to the State of California to cause cancer. See P65Warnings.ca.gov for more information.
Manuals & videos
- Secure checkout
- 21-day return requests
- Free standard shipping $100+
Product facts
- CT SKU
- CT-109684
- Model / MPN
- P501J-118S-3A
- UPC / GTIN
- 671880841955
- Package dimensions (H × W × L)
- 6" X 6" X 15"
- Package weight
- 8.4 lb
- Country of origin
- CHINA
Specifications
- Volts
- 12v
- Max PSI
- 60
- Gallons Per Minute
- 5 GPM
