Brand: Raymarine
Raymarine CAM400 Augmented Reality Bundle, White (T70603)
Raymarine CAM400 Augmented Reality Bundle, White (T70603)
2 available
About this product
The Raymarine CAM400 Augmented Reality Bundle combines a white fixed-mount marine IP camera with an AR200 sensor for onboard monitoring and augmented-reality viewing on compatible Raymarine Axiom displays.
- Full HD 1080p video with a 129-degree horizontal field of view and integrated infrared illumination.
- Supports standalone or multi-camera use, with video streaming, image flip and invert functions, and Power over Ethernet or 12 V DC power options.
- ClearCruise augmented reality overlays navigation aids, AIS targets, waypoints, and chart objects when paired with a compatible Axiom chartplotter.
- Optional on-screen distance lines are available with LightHouse 5 on Axiom 2 systems.
- AR200 sensor features a 9-axis AHRS, 28-channel GPS receiver, 10 Hz position updates, and SBAS support for WAAS, EGNOS, MSAS, and GAGAN. It provides position, heading, pitch, and roll data to compatible Axiom displays.
- The AR200 is NMEA 2000 compliant and rated IPX6/IPX7.
- Includes CAM400 camera (E70716), AR200 sensor (E70537), 10 m RayNet-to-RayNet cable (A62362), 1 m STNG backbone cable (A06034), and STNG T-piece connector (A06028).
- Factory-installed RayNet Ethernet pigtail; no waterproof RJ-45 coupler is required.
Compatible with Raymarine Axiom and Axiom 2 chartplotters. ClearCruise augmented reality requires a compatible Axiom chartplotter and AR200 sensor.
