Brand: Trident Marine
Trident Marine 5/16 in. x 50 ft. Low Permeation Type A1-15 Fuel Line Hose
Trident Marine 5/16 in. x 50 ft. Low Permeation Type A1-15 Fuel Line Hose
Last one
About this product
This Trident Marine fuel hose is designed for distribution, return, vent, and transfer applications in marine environments. It features a specialized barrier liner that prevents fuel from directly contacting the rubber tube, providing effective resistance to fuel permeation, fire, heat, and aging.
Key Features:
- Compatible with all marine fuels, including gasoline, alcohol blends, diesel, and biodiesel up to B100
- Constructed with a nylon internal barrier and NBR tube, NBR/PVC blend cover, and polyester 2-spiral reinforcement
- NMMA type accepted and CE certified
- Temperature range: -20°F to 212°F (-28°C to 100°C)
- Inner diameter: 5/16 in. (7.92 mm)
- Outer diameter: 0.611 in. (15.5 mm)
- Working pressure: 100 psi (0.69 mpa)
- Burst pressure: 400 psi (2.76 mpa)
- Bend radius: 1.75 in. (44.5 mm)
- Length: 50 ft. (15 m), supplied in a box
The #365 series meets or exceeds ABYC H-24 and H-33, SAE J1527, ISO 7840, and USCG Type A1-15 standards. It is CARB Executive Order RM-17-008 and EPA certified for low permeation. Manufacturer part number: 365-0566.
Manuals & videos
- Secure checkout
- 21-day return requests
- Free standard shipping $100+
Product facts
- CT SKU
- CT-112570
- Model / MPN
- 365-0566
- UPC / GTIN
- 704917010564
- Package dimensions (H × W × L)
- 3" X 18" X 18"
- Package weight
- 7.9 lb
- Country of origin
- UNITED STATES
Specifications
- ID Diameter (inches)
- 5/16"
- Length (Feet)
- 50'
