Xantrex MPPT 60A Solar Charge Controller, 150V PV, UL/CSA Certified

Maximize your solar energy harvest and extend battery life with the Xantrex MPPT 60A Solar Charge Controller. Engineered for superior efficiency and smart solar performance, this controller utilizes advanced Maximum Power Point Tracking (MPPT) technology to deliver up to 30% more power compared to traditional PWM controllers. It's the ideal solution for robust and reliable solar power management in diverse applications from RVs to marine systems. Upgrade your solar system's intelligence and efficiency today.

In the Box:

• Xantrex MPPT 60A Solar Charge Controller
• Battery Temperature Sensor (BTS)

Key Benefits & Features:

• Advanced MPPT Technology: Achieves an ultra-fast tracking speed and up to 99.5% efficiency, maximizing power output from your solar panels even under varying environmental conditions.
• Wide System Voltage Compatibility: Optimized for charging 12V, 24V, 36V, and 48V DC battery banks, with auto-detect functionality for seamless integration.
• Versatile Battery Support: Compatible with a broad range of battery chemistries, including Lithium, Lead-acid (AGM, Gel, Flooded), and custom types, ensuring optimal charging for your specific setup.
• High PV Input & Charging Current: Supports up to 150V PV input and delivers a robust 60A charging current to efficiently power your system.
• Comprehensive Connectivity: Features built-in RV-C, Modbus, and Bluetooth BLE modules for real-time monitoring, comprehensive historical data, and ultimate control via the Xantrex Solar App.
• Enhanced Battery Protection: Employs multi-stage charging (Bulk, Absorption, Float, Equalization), battery temperature compensation, and dynamic power reduction to prevent overcharging, protect against short-circuiting, and prolong battery lifespan.
• Convection Cooled Design: Operates silently without the need for a cooling fan, utilizing a large aluminum heatsink for full output current up to 45°C without thermal derating.
• Certified Safety: ETL listed and compliant with UL1741 and CSA C22.2#107.1 standards, ensuring safety and adherence to North American electrical codes.

Recommended Pairings: For advanced system monitoring and control, pair with the optional Xantrex Solar MPPT Remote Panel (710-0010) or integrate into a larger Xanbus-enabled network.
